Enclosure Series

Features:

*Start the cooling fan manually or automatically(oil temperature、load), remote controlling and other controlling modes.
* Connect Computers and RTU easily, meeting the power part's requirements of telemetry, teledata and remote control.
* Adopt advanced electric and electronic apparatus to supplant the traditional relays and connectors, with the advantages of long life span, high reliability and non-mechanical contact point, high sensitivity and low electromagnetic interference.
* The enclosure with stainless steel and special treatment outside is well-shaped and durable .

FG-J series：（mail loop adopt touch switch apparatus）
Model
Ph-Volt
Remote-control
max current
Quantity
Fan Power
Running rules
Fault joint
Manual
Auto
Remote-control
Oil temperature
Load
FG-JL6-2
380
√
√
 　　
√
 　　
5
6
0.25
　　
　　
FG-JL24-3
380
√
√
 　　
√
√
25
24
0.37
　　
√
FG-JP24-3
380
√
√
 　　
√
√
25
24
0.37
　　
√
FG-JZ2-3
380
√
√
√
√
√
15
12
0.37
CDT
√
FG-JZ8-7
380
√
√
√
√
√
30
8
1.5
CDT
√

FG-Series:（Main loop adopt non-connect point electric&electronic）

Model
Ph-Volt
Remote-control
max current
Quantity
Fan Power
Running rules
Fault joint
Manual
Auto
Remote-control
Oil temperature
Load
FG-SL8-7
380
√
　　
　　
√
√
25
8
1.5
 　　
√
FG-SP8-5
380
√
√
 　　
√
√
15
8
0.75
 　　
√
FG-SZ12-3
380
√
√
√
√
√
10
12
0.37
CDT
√
FG-SZ24-2
380
√
√
√
√
√
12
24
0.25
CDT
√
FG-SZ8-7
380
√
√
√
√
√
25
8
1.5
CDT
√
FG-SZ8-8
380
√
√
√
√
√
38
8
2.2
CDT
√
