Fan Model:FB2-P4-D600(60Hz)
DIA&Blade
HP
PH
RPM
Voltage(V)
Name AMPS(A)
Running AMPS(A)
Fan Volume
Dynamic Pressure(Pa)
dBa
Weigh(kg)
24'* 2wing
1/3
1
1750
208-230
2.4
2.3
7000CFM
63
68.5
23
110-120
4.8
4.6
24'* 2wing
1/3
3
1750
460-480
0.67
0.62
7000CFM
63
68.5
23
230-240
1.4
1.3

Fan Model:FB2-P4-D600(50Hz)

DIA&Blade
Power
PH
RPM
Voltage(V)
Name AMPS(A)
Running AMPS(A)
Fan Volume
Dynamic Pressure(Pa)
dBa
Weigh(kg)
24'* 2wing
370W
3
1450
380-415
0.97
0.72
9800m3/h
49
62
24

Protection class IP55 Insulation class F

Naming rules:F=Fan B2=Two Blades P4=Four Poles D600=The diameter of impeller is 600mm.

NOTE:

1.The Fan performance parameters wer measured according to ISO 5801:1997(E)、<<Industry ventilation Fan Testing Standard>>、Experiment type A.

2.Noise levelis measured at 2M from the fan.
