| Fan Model:FB4-P8-D700(60Hz) |
|
|
DIA&Blade
|
HP
|
PH
|
RPM
|
Voltage(V)
|
Name AMPS(A)
|
Running AMPS(A)
|
Fan Volume
|
Dynamic Pressure(Pa)
|
dBa
|
Weigh(kg)
|
|
27＇* 4wing
|
1/6
|
1
|
850
|
208-230
|
1.40
|
1.26
|
5840CFM
|
36
|
58
|
29
|
|
115
|
2.80
|
2.68
|
|
27＇* 4wing
|
1/6
|
3
|
850
|
460
|
0.74
|
0.72
|
5840CFM
|
36
|
58
|
29
|
|
230
|
1.50
|
1.46
|
Fan Model:FB4-P8-D700(50Hz)
DIA&Blade |
Power |
PH |
RPM |
Voltage(V) |
Name AMPS(A) |
Running AMPS(A) |
Fan Volume |
Dynamic Pressure(Pa) |
dBa |
Weigh(kg) |
27＇* 4wing |
185W |
3 |
950 |
380-415 |
0.74 |
0.6 |
9000m3/h |
32 |
55 |
28 |
 Protection
class IP55 Insulation class F
Naming
rules:F=Fan B4=Four
Blades P8=Eight Poles D700=The diameter of impeller is 700mm.
Sound
level is measured at 2m from the motor when the fan is working
on transformer.
|
